NH15 Compact Escape Hood

NH15 Compact Escape Hood

Brand: AVON Protection
AVON Protection NH15 Escape Hood

CBRN Air Purifying Escape Respirator

The NH15 hood has a five year shelf life and provides a high level of respiratory, eye and face protection for a minimum of fifteen minutes. Made of clear material, the NH15 not only protects against all airborne CBRN threats but also protects the face from liquid agent splashes.

Key Features:

  • Suitable for First Responders, Military, Prisons and Corrections
  • Five year shelf life
  • Superior visual communication
  • NIOSH CBRN approved TC-14G-0302
  • PPE Directive 89/686/EEC for CE marking
  • Minimum 15 Minute Escape Hood

Ideal For:

  • Law Enforcement
  • Corrections
  • Federal Government
  • Military
  • Industrial / Municipal Services
  • Fire / CBRNe

Get more information or request a quote on AVON Protection solutions from Safeware.

By submitting a request for quote, you are agreeing to allow emails and contact from Safeware, Inc.

Already registered under a cooperative contract? Shop now at safewarecontracts.com
SHOP NOW UNDER CONTRACT

Share This:

  • Description
  • Features
  • Specifications
  • Downloads

The Avon Protection NH15 CBRN Air Purifying Escape Respirator is the smallest and most compact escape hood on the market, approved to carry NIOSH and CE marking. Its low cost makes it ideal for police, emergency medical services and fire officers seeking immediate or emergency respiratory protection in a CBRN scenario.



The NH15 hood has a five year shelf life and provides a high level of respiratory, eye and face protection for a minimum of fifteen minutes. Made of clear material, the NH15 not only protects against all airborne CBRN threats but also protects the face from liquid agent splashes.



The clear material gives a non-threatening appearance, aids with recognition of the wearer and also allows for superior visual communication. Twin low-profile filters on a unique hinge system feature the latest filtration media which reduces breathing resistance and a front reflector makes it easier to identify colleagues in low light environments.

Features and Benefits

Compact

  • Low Profile Filters to reduce snagging
  • Streamlined design

See and Be Seen

  • Clear range of vision
  • Reflective label

Fit and Comfort

  • Close fit filters
  • Self-Adjusting Harness
  • 3 sizes

Cost of Ownership

  • No fit test requirements
  • No replaceable parts
  • No maintenance or inspections

Technical Specifications

Technical Data
Protection Factor & Hood Performance
Breathing Zone (Oronasal) Greater than 2,000
Head zone (Ocular) Greater than 150
Neck size ranger 330-558mm (regular)
Donning time Less than 30s
Re-breathing CO2 Less than 2.0%
Breathing Resistance
Inhalation at 85lpm Less than 50 mm H20
Exhalation at 85lpm Less than 10 mm H20
Barrier Performance (Tested at ECBC)
GB Greater than 30 minutes
HD Greater than 30 minutes
Smartman Performance (Tested at ECBC)
GB Greater than 30 minutes
HD Greater than 30 minutes
Filter Performance P3/P100 (Less than 0.03%)
Particulate Penetration P100 (Less than 0.03%)
Packaging
Pack Size 6″ X 4″ X 3.4″ in (150 X 100 X 90 mm)
Packaging type 4 layer foil barrier bag surrounded by reinforced nylon carrier
Weight (as carried) 1 lb 7 oz (625g)
Packaged shelf life 5 years when stored between 5°F and 105°F
User instructions 3 language user guide supplied
Sizing
Extra Small 12 to 13 inches
Regular 13 to 18 inches
Large 18 to 22 inches
Typical Filter Performance Data
  Challenge Concentration (ppm) Breakthrough Time (minutes)
Hydrogen Sulfide 500 > 150 Minutes
Ammonia 1250 > 20 Minutes
Sulphur Dioxide 750 > 30 Minutes
Cyclohexane 1300 > 35 Minutes
Formaldehyde 250 > 45 Minutes
Hydrogen Cyanide 470 > 45 Minutes
Nitrogen Dioxide 100 > 45 Minutes
Phosphine 150 > 45 Minutes
Phosgene 125 > 45 Minutes
Cyanogen Chloride 150 > 30 Minutes
NIOSH Logo



NIOSH CBRN approved TC-14G-0302

CE Mark



PPE Directive 89/686/EEC for CE marking, Article 10 type-examination approval to BS8468-3.2:2009 type-1: Certificate No. CEC 40136 A2

Keyword Tags:

avon protectioncbrnceescape hoodnh15nioshniosh-cbrn
