Gemini™ - Handheld Chemical Identification Analyzer
FTIR and Raman Spectroscopy
Identify unknown chemicals and explosives in the field quickly, safely, and confidently with the power of FTIR and Raman spectroscopy in a single handheld instrument.
Ideal for:
- First Responders
- Federal Government Agencies
- Military CBRNE Operations
- Corrections Officers
- Counter Terrorism Operations
Request a quote from Safeware on the Gemini™ Chemical Identification Analyzer to see how you can save time and money using any of our national or local cooperative contracts. Any state. Any time.
Identify a broad range of unknown chemicals and explosives in the field using FTIR and Raman spectroscopy in a single instrument, including low concentration analysis. The rugged, compact Thermo Scientific™ Gemini™ analyzer meets the demanding requirements of elite military and public safety forces, helping operators execute their mission quickly, safely, and accurately.
The Gemini Analyzer is the first and only integrated Raman and FTIR handheld instrument in the world, providing complementary and confirmatory testing in a single, field-portable device.
Better, faster decision making
- Lightweight and compact, ideal for chemical battalions, explosive ordnance disposal (EOD) technicians and other first responders burdened with heavy equipment.
- Virtual mixture analysis and interactive problem solving on scene with HazMasterG3.
- Includes 24/7 reachback support with access to Ph.D. spectroscopists for spectral analysis and operational inquiries.
Increased confidence in results
- Leverages both Raman and FTIR technology to address a broader range of samples than either technique alone.
- Identifies unknown solids and liquids, from explosives and chemical warfare agents to industrial chemicals and precursors using a comprehensive onboard library.
- Builds on the field-proven performance of Thermo Scientific™ FirstDefender™ and Thermo Scientific™ TruDefender™ Analyzers.
Safer Operation
- Includes a motorized anvil which adjusts sample pressure based on user settings.
- Features Raman and FTIR Scan Delay to allow users to leave the hazard zone before initiating a scan.
Easier to use, enhanced efficiency
- Guides the operator through technology selection and sampling with Scan Assist.
- Customizable Profiles allow the operator to set scan parameters based on the sample, scenario, and their situational awareness
- Minimizes user error and eliminates subjective user interpretation.
- Requires minimal training for proficiency.
Features and Benefits
3 Technologies in 1
- FTIR
- RAMAN
- Surface Enhanced Raman Spectroscopy - Low concentration analysis
Be Prepared and Aware
- HazMaster G3 Software (add on capability)
- Determine potential hazardous material being made from on site chemicals
- Determine what HME formula ingredients are missing
Easy to Understand
- Two Scan Formats - ID Mode and Screener mode
- Intuitive operation - The graphical interface ensures that minimal training is required for proficiency
- Flexible input - Navigate features using either the tactile keypad or resistive touch screen
Support
- 5 years of support - Reachback support
- Software updates
- Library updates
- Inquire about the Hazard3 FINDER Course for integration to your current equipment
Technical Specifications
| Specifications | |
|---|---|
|
Product Type |
Handheld Raman/FTIR Spectrometer |
|
Certifications/Compliance |
Certified to MIL-STD-810G and IP67; full test report available on request |
|
Collection Optics |
FTIR: ATR diamond crystal, single bounce Raman: NA= 0.33 |
|
Data Export Formats |
SPC file (for use in standard spectroscopic software), text file, or JPEG report |
|
Dimensions (L x W x H) |
10.1 x 5.7 x 2.4 in. (25.6 x 14.6 x 6.1 cm) |
|
IP Rating |
IP67 |
|
Power Supply |
Internal 3.7 V lithium polymer (QTY 1) battery pack Internal CR123A (QTY 3) batteries DC wall adapter, 12 V DC, 1.25 A |
|
Spectral Range |
FTIR: 4,000 cm-1 to 650 cm-1 Raman: 250 cm-1 to 2875 cm-1 |
|
Temperature Range (Metric) |
-20°C to +50°C |
|
Weight (English) |
4.2 lb. |
Product Literature
Safety Data Sheets
Application Notes
- FTIR & Raman: Complimentary Technologies for First Responders
- Case Study: Turkey at the Crosssroads with Gemini Analyzers
- White Paper: Lesser and Lesser becoming Deadlier and Deadlier: Detecting Low Doeses of Lethal Opioids
- White Paper: The Thermo Scientific Gemini Analyzer with LowDoseID for Detection of Low Concentration Illicit Drugs
- Attack the Network with Gemini and HazMaster G3
- Technology and Training Critical in Evolving EOD Landscape
